Products:

UV lamp SP

A UV lamp is an easy way to kill bacteria and make the water in your swimming pool clean with minimum use of chlorine. The water flows into the lamp body, where it is exposed to UV light, and comes out free of germs and bacteria.

Questions? Talk To Us!

We are here to help you to choose the solution that fits your needs.

Contact Us

Basic Information

Water treated with our BRILIX UV lamp doesn´t contain any bacterias, viruses or other gems. Thanks to the UV lamp you can reduce the amount of chlorine and other chemicals used for water treatment for 80% and help to save environment and health of your children. The UV lamp is made of electrolytically refined stainless steel which prevents sedimentation of impurities.

The use of the SP UV lamp is an elegant way of ensuring clean water in the swimming pool without using chlorine. Before returning to the pool, all the filtered water flows through the UV lamp body, where it is exposed to UV radiation. It eliminates all harmful germs and bacteria and the water in your swimming pool is pure even without the use of chemicals.

Details

UV lamp details



Technical information

Model SP - I SP - II SP - III SP - IV SP - V
A (mm) 276 786 786 786 786
B (mm) 175 175 175 175 175
C (mm) 155 155 155 155 155
D (mm) 420 930 930 930 930
Pipe diameter 1 1/2" 1 1/2" 1 1/2" 1 1/2" 1 1/2"
Voltage 230V 230V 230V 230V 230V
Input 16 W 40 W 65 W 85 W 2x85 W
Water flow rate 6 m3/hour 9 m3/hour 12 m3/hour 15 m3/hour 20 m3/hour
Maximum pressure 3 bar 3 bar 3 bar 3 bar 3 bar
For pools up to 15 m3 35 m3 55 m3 70 m3 140 m3



UV lamp sizes

We do not recommend using UV lamps in swimming pools with salt water.

Recommendation

Recommended accessories

Pool enclosure

for the most cost-effective swimming pool heating.
